Controlled by Soft Start & Slow Stop System

Controlled by Inching Drive (Slow Speed Drive) System

Main Drive Controlled by Inverter System

Stop Motion Controls

Operator Safety Controls

Track Oiling System

Braid Pitch Controlled by Change Gear or variation

Connected with Tack-up and Pay-off available to auto product line

 Specification

Division

16 Carrier

24 Carrier

Type

    Vertical or Horizontal

Gross weight

 Vertical   : 680kg

 Horizontal : 1600kg

Vertical   : 700kg

 Horizontal : 1620kg

Floor Space

Vertical   : 1.6 sq M

 Horizontal : 1.9 sq M

Vertical   : 1.6 sq M

 Horizontal : 1.9 sq M

Carrier R.P.M

100rpm

80rpm

Bobbin capacity

260cc

Carrier tension

0.5kg - 1.8kg

 Usage material

Yarn, Soft Copper Wire, Soft Steel Wire

 Dia, of braid

Max  Ø22mm

Drive motor

 Vertical   : 2HP*6P

 Horizontal : 5HP*4P

 Vertical   : 3HP*6P

 Horizontal : 5HP*4P
